SHACMAN H3000 6X4 Trailer Truck

Horsepower: 430/460/480/500 HP

Transmission: FAST

Fuel Tank: 400/600/800L

Drive Type: 6×4/4×2

Color:Custom Configuration

Hotline:+8618660194444


Parameter
Specification
Vehicle Model
SHACMAN H3000 6×4 Trailer Truck
Vehicle Type
Trailer Truck / Tractor Head
Drive Type
6×4
Cabin Model
H3000 High Roof Cabin
Driving Type
LHD / RHD
Seat Configuration
2 Seats + 1 Sleeper
Air Conditioner
Equipped
Electric Window
Equipped
Central Lock
Equipped
Multifunction Steering Wheel
Optional
Engine Brand
WEICHAI / CUMMINS
Engine Model
WP12 / WP13 Series
Horsepower
430 HP / 460 HP / 480 HP / 500 HP
Emission Standard
Euro II / Euro III / Euro V / Euro VI
Displacement
11.6L – 12.54L
Maximum Torque
2100–2400 N·m
Fuel Type
Diesel
Fuel Tank Capacity
400L / 600L / 800L
Transmission Brand
FAST
Transmission Model
12JSDX / 16JSD Series
Gearbox
12 Forward & 2 Reverse / 16 Forward & 2 Reverse
Clutch
430 mm Diaphragm Clutch
Front Axle
7.5T MAN Axle
Rear Axle
13T / 16T MAN Reduction Axle ×2
Axle Ratio
3.7 / 4.11 / 4.77
Steering System
ZF Hydraulic Steering
Brake System
Dual Circuit Air Brake
Parking Brake
Spring Energy Brake
ABS
Optional
Retarder
Optional
Suspension
Heavy-duty Multi-leaf Spring
Frame
High-strength Double-layer Frame
Tire Specification
12.00R20 / 315/80R22.5
Number Of Tires
10 + 1 Spare Tire
Wheelbase
3175 + 1400 mm
Overall Dimension
6800 × 2550 × 3950 mm
Fifth Wheel Size
50# / 90#
Fifth Wheel Brand
JOST Optional
Kingpin Compatibility
2 Inch / 3.5 Inch
GVW
25000 kg
Curb Weight
8800 kg
GCW
50000–80000 kg
Maximum Speed
110 km/h
Gradeability
30%
Ground Clearance
314 mm
Application
Container Transport, Logistics, Long-distance Freight, Bulk Cargo Transport
Optional Configuration
Customized Configuration Supported
