Steering wheel

LHD/ RHD

Load capacity (T)

5

GVW（Kg）

7500

Emission standard

 Euro Ⅱ

Driver's cab

 single row

Wheelbase

3360

Driving form

4×2

Vehicle model

Aumark E

Vehicle width（mm)

1880

Announcement model

BJ1065VDJDA-F1

External dimensions(mm)

5995X1935X2225

Engine model

YC493ZLQV1

Engine manufacturer

YUCHAI

Fuel type

DIESEL

Power

80

Horsepower

102

Transmission model

5G32

Transmission manufacturer

WLY

Front axle

2.4T

Rear axle

4.5T

Rear axle speed ratio

5.375

Brake control
system

ABS

Tire

7.00R16

Fuel tank capacity

120L

Basic configuration

Single top-mounted filing cabinet, double sunshades, no front lower mirror, no heated rearview mirror, width 1880, single-row driver's cabin, no deflector cover, no deflector plate, side turn signals (door, without turning light), electric heating, no cruise control, no reverse radar, no reverse horn, 12V battery, no cargo box accessories, no automatic headlights, 1590/1485, no side protection, steel rim, ordinary body, manual window lift, no central locking + mechanical door lock + two flat plastic fuel tanks, 120L, φ265mm diaphragm spring clutch, pneumatic braking, constant pressure exhaust braking, aluminum alloy air reservoir, front and rear drum brakes, emergency braking, ABS (4S4M), 2.4t front axle, 4.5t, NPR single-stage reduction drive axle, impact welding, steel rear protection, fog lights, door not closed warning, main driver's seat belt not fastened alarm, internal rearview mirror.

Air-conditioning

Optional

Number of tires

Double rear tyres 6+1pcs

Optional projects(Optional items come at an additional cost)

Electirc AC

Container configuration parameters

4100x1960x400,bottom 4mm, side 3mm,Q235
